Hopkins Build ref: 466



General Information

466 is the first pop up roof transporter we have manufactured from a complete automated 3d model, The design was based on the experience gained in build 328 and 300, although very similar in appearance approximately 90% of the design was new to reduce weight, build time and ease access for servicing.

Detailed Specs

External: 13.6m x 4m travelling height race transporter, 2,500kg 2 tier dhollandia Tail lift, 13 kva marine application generator, hydrovane compressor, self seeking satellite, wireless internet, HMS hydraulic pop up roof, 2 x 13m x 8 awnings, 8m mast,  Pop up roof to give 2.2m when projected.

Workshop: The workshop area has a fixed height of 2mtrs, it will carry 2 Formula cars, at th circuit the rear section converts to a  drivers area, during transit the rear benchs also fold up to maximise storage possibilities.

Top Deck: The top deck has a 1300mm height when travelling that will allow for the storage of 2 cars or flight cases and pit equipment to be transported.  In circuit configuration it forms an engineers office for 8 engineers and six drivers, the seats all travel in a folded up position and simply fold down at the circuit to minimise set up time, the area is also fitted with circuit data TV’s and satellite TV, remote printers, air conditioning.

Management office: On the goose neck is a management office that functions with the roof up only, external storage lockers are below the office. Individual air conditioning, satellite, removable table for additional storage, leather seating, sued walls as per the engineer’s room.

Drivers room: In under 5 minutes a separate room can be installed at the rear of the top deck that can act as beds or seating for the drivers with room to hang overalls and have massages etc.

466

466 Pop Up Roof Race Transporter
